Brand:
ENERPAC
PAM1022
Air driven Hydraulic pump, use with Single Acting cylinder, 8 Lit Oil Reservoir, 3/2 manual valve
Made in: ENERPAC USA
B2B Project Supply & Genuine Technical Support
Request a Project Quotation & Technical Advice
This product belongs to our range of high-specification industrial equipment. Please contact the Davita technical team for detailed specifications, stock availability and our best project pricing.
100% Genuine (CO/CQ)
Manufacturer Standard Warranty
Nationwide Delivery
24/7 Technical Support
1. Order code: PAM1022
2. Description: Air driven Hydraulic Pump, 3/2 Manual Valve, 7,6 litres Usable Oil, For use with Single-Acting Cylinders/ Bơm thủy chạy bằng Khí nén, bình dầu 7.6 Lit, dùng với kích thủy lực/ xi lanh thủy lực 1 chiều, dùng van tay loại 3/2 (3 cổng, 2 vị trí)
3. Technical Specifications
| Specification | Value |
|---|---|
| Maximum Operating Pressure | 700 bar |
| Cylinder Compatibility/ Tương thích với xi lanh | Single-acting/ Tác động đơn (kích 1 chiều) |
| Reservoir Capacity (cm³) | 7600 cm³ |
| Reservoir Capacity (litres) | 8 litres |
| Usable Oil Capacity | 7.6 litres |
| Maximum Flow at Rated Pressure | 0.15 l/min |
| Output Flow Rate 1st Stage | 10.65 l/min |
| Output Flow Rate 2nd Stage | 0.15 l/min |
| Valve Function | Advance / Retract |
| Valve Operation | Manual |
| Valve Type | 3-way, 2-position |
| Valve Model | VM2 |
| Power Source/ Nguồn dẫn động | Air / Khí nén |
| Pump Control / Điều khiển Bơm | Manual / Vận hành tay |
| Air Pressure Range / Dải áp suất khí nén cung cấp | 4.1 – 8.3 bar |
| Air Consumption / Lưu lượng khí nén tiêu thụ | 510 l/min |
| Sound Level / Mức độ ồn | 87 dBA |
| Weight | 27.2 kg |
4. Product Dimensions
| Dimension | Metric | Imperial |
|---|---|---|
| Height | 457 mm | 18.00" |
| Length | 320 mm | 12.63" |
| Width | 308 mm | 12.13" |
5. Complete Your System/ Hoàn thiện hệ thống cần thêm:
- Gauge / Đồng hồ đo áp
- Hose / Đường ống thủy lực
- Hydraulic Oil / Dầu thủy lực
